A vertical anchor windlass keeps the motor below deck while the gypsy handles chain and rope at the bow, but the right choice depends on your rode, mounting space, and anchoring habits. I rank the Lewmar V700 as the best overall vertical pick in this lineup for buyers seeking a dedicated vertical windlass with matching controls and chain-specific options. The Excalibur 900W stands out for buyers who want a higher-powered vertical system, while the VEVOR fishing windlasses suit a narrower fishing-focused use case. Several listed Five Oceans Atlantic 600 models are horizontal, not vertical, so they are useful only if you are open to a different layout. Read on for the full comparison and the fit checks that matter before you buy.
Get sports gear delivered free with Prime
- Fast, free delivery on millions of items
- Prime Video, Amazon Music and more included
- Member-only deals all year
Complete the kit
Key Takeaways
- The Lewmar V700 models are the clearest all-around vertical choices; compare their included controls and specified chain compatibility rather than assuming the listings are identical.
- Excalibur’s 600W and 900W vertical systems separate by power and configuration, while the capstan version adds a handling option that may matter beyond anchor retrieval.
- VEVOR’s fishing windlasses serve a different job from conventional anchor windlasses, so their boat-size and pull specifications should not be treated as direct substitutes for chain-and-rope systems.
- Most Five Oceans Atlantic 600 listings are horizontal windlasses; duplicated or near-duplicated titles make model verification and mounting-style checks especially important.
- Chain size, rode type, and deck geometry are decisive: a stronger motor cannot compensate for an incompatible gypsy or a bow layout that cannot accept the windlass.
| VEVOR 12V Vertical Fishing Windlass for 20–36 ft Boats |  | Best for Quick Anchor Drops | Power: 12V DC | Maximum pull: 700 lb | Working load: 176 lb | VIEW ON AMAZON | See Our Full Breakdown |
| Five Oceans Atlantic 600 Series 12V Horizontal Electric Boat Windlass Kit |  | Best Complete Rode Kit | Orientation: Horizontal | Power: 12V DC | Motor power: 600W | VIEW ON AMAZON | See Our Full Breakdown |
| Five Oceans Atlantic 600 Series 12V Horizontal Electric Anchor Windlass Kit |  | Best for Spec-Minded Kit Buyers | Orientation: Horizontal | Power: 12V | Motor power: 600W | VIEW ON AMAZON | See Our Full Breakdown |
| Five Oceans Atlantic 600 Series 12V Horizontal Electric Windlass Anchor Kit |  | Best Controls-Included Alternative | Orientation and installation: Horizontal, on-deck | Power: 12V | Motor power: 600W | VIEW ON AMAZON | See Our Full Breakdown |
| Excalibur 600W 12V Vertical Windlass Anchor System for Boats up to 40 ft |  | Best Vertical All-Rounder | Orientation: Vertical | Motor power: 600W | Voltage: 12V DC | VIEW ON AMAZON | See Our Full Breakdown |
| Five Oceans Atlantic 600 Series 12V Horizontal Electric Windlass Anchor Kit |  | Best Complete Horizontal Kit | Type: Horizontal electric windlass | Voltage and motor power: 12V DC, 600W | Maximum pulling power: 1,200 lb (540 kg) | VIEW ON AMAZON | See Our Full Breakdown |
| Excalibur 900W 12V Vertical Windlass Anchor System for Boats up to 40 ft |  | Best for Fast Retrieval | Type: Vertical electric windlass | Voltage and motor power: 12V DC, 900W | Current draw: 55A | VIEW ON AMAZON | See Our Full Breakdown |
| VEVOR 12V DC Fishing Windlass for Boats 23-29.5 ft, Max Pull 573 lbs, Stainless Steel |  | Best Compact Fishing Pick | Type: 12V DC fishing windlass | Maximum pull: 573 lb | Suitable boat length: 23–29.5 ft | VIEW ON AMAZON | See Our Full Breakdown |
| Lewmar V700 Vertical Windlass with Solenoid and Rocker Switch |  | Best for Chain Compatibility | Model: Lewmar V700 | Deck unit material: 316 stainless steel | Chain compatibility: 6 mm DIN766, 1/4 in G4 or BBB, 7 mm DIN766 | VIEW ON AMAZON | See Our Full Breakdown |
| Lewmar V700 12V Vertical Windlass for 1/4-Inch G4 Chain |  | Best Value Vertical Lewmar | Model: Lewmar V700 | Voltage: 12V | Maximum pull: 700 lb | VIEW ON AMAZON | See Our Full Breakdown |
| Lewmar Pro Sport 550 12V Windlass for 1/4″ G4 Chain, Manual Freefall, Port Side Mounted, for Boats 20′-30′ |  | Best for Smaller Boats | Voltage: 12V | Maximum pull: 550 lbs. | Chain compatibility: 1/4-inch G4 chain | VIEW ON AMAZON | See Our Full Breakdown |
| Five Oceans 12V Electric Boat Anchor Windlass Kit, 600W |  | Best Complete Kit | Windlass type: Horizontal, on-deck | Voltage and motor power: 12V, 600W | Maximum pulling power: 1,200 lbs. / 540 kg | VIEW ON AMAZON | See Our Full Breakdown |
| Five Oceans Atlantic 600 Series 12V Horizontal Electric Boat Windlass Kit |  | Best for Supplied Controls | Installation: Horizontal, on-deck | Voltage and motor power: 12V, 600W | Maximum pulling power: 1,200 lbs. / 540 kg | VIEW ON AMAZON | See Our Full Breakdown |
| Lewmar Pro-Fish 700 Fishing Windlass with Auto Free-Fall |  | Best for Fast Anchor Deployment | Installation: Above-deck, horizontal | Chain compatibility: 1/4-inch G4 | Recommended boat length: 28–38 ft | VIEW ON AMAZON | See Our Full Breakdown |
| Excalibur 600W Vertical Windlass Anchor System with Capstan, 12V DC |  | Best Vertical Pick with Capstan | Windlass format: Vertical | Motor and voltage: 600W, 12V DC | Current draw: 33A | VIEW ON AMAZON | See Our Full Breakdown |
More Details on Our Top Picks
VEVOR 12V Vertical Fishing Windlass for 20–36 ft Boats
The VEVOR 12V Vertical Fishing Windlass is the standout here for boaters who value rapid anchor deployment: its free-fall release and stated 65 ft/min retrieval speed are tailored to frequent fishing stops. Its 316 stainless steel construction and IP67 rating offer stronger stated water protection than the Five Oceans Atlantic 600 Series, which is rated IP66, though that kit supplies a more complete rope-and-chain rode. VEVOR’s 700 lb maximum pull is lower than the Five Oceans kit’s 1,200 lb, so I’d treat this as a focused fishing windlass rather than the heavy-duty choice in this group. It accepts only 1/4-inch chain and specified nylon rope, and direct mounting calls for a 1-3/8-inch deck. That fit requirement can rule it out before the performance specs matter.
Pros:- Free-fall release supports quick anchor drops during frequent fishing stops.
- 316 stainless steel construction is intended to resist marine corrosion.
- IP67 rating provides a higher stated water-protection level than the IP66 Five Oceans kits.
- Includes two foot switches and a solenoid valve.
Cons:- 700 lb maximum pull is below the Five Oceans Atlantic 600 Series rating of 1,200 lb.
- Works with only the listed 1/4-inch chain and 9/16–5/8-inch nylon rope sizes.
- Direct mounting requires a 1-3/8-inch-thick deck.
Best for: Fishing-boat owners with a 20–36 ft vessel, compatible rode, and a priority on fast free-fall deployment.
Not ideal for: Owners seeking higher stated pulling capacity, a supplied rope-and-chain rode, or a windlass that fits decks other than the specified 1-3/8-inch thickness.
- Power:12V DC
- Maximum pull:700 lb
- Working load:176 lb
- Retrieval speed:65 ft/min
- Chain compatibility:1/4 in
- Rope compatibility:9/16–5/8 in nylon rope
- Compatible boat length:20–36 ft
- Water protection:IP67
- Deck mounting thickness:1-3/8 in
Our verdict“Choose the VEVOR if free-fall fishing deployment and its specified mounting fit matter more than a higher pull rating or a complete rode kit.”
Five Oceans Atlantic 600 Series 12V Horizontal Electric Boat Windlass Kit
I’d rank the Five Oceans Atlantic 600 Series kit as the strongest pick for buyers who want the windlass and core rode components together. It includes 150 ft of nylon rope and 15 ft of galvanized chain, plus switches, solenoid, circuit breaker, mounting hardware, and anchor connectors. Its 600W motor and 1,200 lb maximum limit pulling power exceed the VEVOR fishing windlass’s 700 lb maximum, but this is a horizontal, on-deck design, not a vertical model. That distinction matters for a roundup centered on vertical anchor windlasses: this is best treated as a practical alternative when deck layout allows horizontal mounting. The 1/4-inch chain and 1/2-inch three-strand rope requirements narrow rode compatibility, and boat suitability depends on vessel design and displacement.
Pros:- Includes 150 ft of nylon rope and 15 ft of galvanized HT G4 chain.
- 600W motor is rated for 1,200 lb maximum limit pulling power.
- Kit supplies switches, solenoid, circuit breaker, mounting hardware, and anchor connectors.
- 316 stainless steel housing and IP66-rated motor are specified for marine use.
Cons:- Horizontal on-deck orientation differs from the vertical focus of this roundup.
- Requires a 12V DC supply and on-deck installation.
- Rode compatibility is limited to specified 1/4-inch chain and 1/2-inch three-strand rope.
Best for: Owners of 20–45 ft boats who want an on-deck horizontal system with rope, chain, controls, and electrical components in one kit.
Not ideal for: Buyers committed to a vertical windlass or whose deck layout cannot accommodate horizontal on-deck mounting.
- Orientation:Horizontal
- Power:12V DC
- Motor power:600W
- Maximum limit pulling power:1,200 lb / 540 kg
- Maximum limit working load:400 lb / 180 kg
- Chain:1/4 in (7 mm) HT G4, 15 ft included
- Rope:1/2 in three-strand nylon, 150 ft included
- Housing:Polished and anodized 316 stainless steel
- Suggested boat length:20–45 ft, depending on vessel design and displacement
Our verdict“Pick this kit when a complete rode and installation package matters more than having a vertical windlass.”
Five Oceans Atlantic 600 Series 12V Horizontal Electric Anchor Windlass Kit
This Atlantic 600 Series version suits buyers who want the kit’s performance and rode details spelled out, including its 4-wire solenoid and 60A circuit breaker. Like the other Five Oceans Atlantic 600 listing, it pairs a 600W motor with 1,200 lb maximum limit pulling power and a supplied rope-and-chain rode. Against the Excalibur 600W vertical windlass, however, it gives up the vertical format and below-deck motor arrangement; the Excalibur is the more direct match for a clean vertical installation, while this one emphasizes a packaged horizontal setup. Its 316 stainless housing and IP66 motor suit marine use, but the 20–45 ft recommendation depends on boat design and displacement. I’d choose it for its specified electrical package, not for a vertical deck profile.
Pros:- Provides detailed electrical components, including a 4-wire solenoid and 60A circuit breaker.
- Includes 150 ft of three-strand nylon rope and 15 ft of galvanized HT G4 chain.
- 600W motor is rated for 1,200 lb maximum limit pulling power.
- 316 stainless steel housing and IP66 motor protection are specified.
Cons:- Horizontal on-deck mounting does not meet a strict vertical-windlass requirement.
- Rode compatibility is limited to 1/4-inch chain and 1/2-inch three-strand rope.
- Recommended boat range depends on vessel design and displacement.
Best for: Boat owners comparing electrical and rode components who need a bundled horizontal system and can install it on deck.
Not ideal for: Buyers who specifically need a vertical windlass, below-deck motor, or an installation tailored to a narrow bow layout.
- Orientation:Horizontal
- Power:12V
- Motor power:600W
- Maximum limit pulling power:1,200 lb / 540 kg
- Maximum limit working load:400 lb / 180 kg
- Rode:1/2 in three-strand nylon, 150 ft; 1/4 in galvanized HT G4 chain, 15 ft
- Solenoid:4-wire
- Circuit breaker:60A
- Mounting:On-deck, three 5/16 in mounting studs
Our verdict“Choose this listing if its clearly specified electrical package and included rode suit your boat and horizontal mounting is acceptable.”
Five Oceans Atlantic 600 Series 12V Horizontal Electric Windlass Anchor Kit
The Five Oceans Atlantic 600 Series kit earns a place for buyers who want multiple controls and anchor connectors supplied rather than sourcing them separately. Its package lists an up/down foot switch, rocker switch, solenoid, 60A breaker, mounting hardware, and a rope-and-chain rode, alongside a 600W motor rated for 1,200 lb maximum pull. Compared with the VEVOR, it offers greater stated pulling capacity and more included installation components, but it lacks the VEVOR’s free-fall fishing focus and IP67 rating. This is still a horizontal on-deck windlass, so it is a compromise option rather than a vertical equivalent. The included chain is 1/4 inch; the listing’s compatibility note about chain up to 1/2 inch should be checked against the actual gypsy and rode before changing sizes.
Pros:- Includes both up/down foot and rocker switches.
- 600W motor has a stated maximum pulling capacity of 1,200 lb.
- Package includes rope, chain, solenoid, breaker, mounting hardware, and anchor connectors.
- Polished, anodized 316 stainless steel housing is designed for marine conditions.
Cons:- Horizontal on-deck installation is not a vertical windlass configuration.
- The included chain is 1/4 inch, so buyers considering a different chain size should verify gypsy compatibility.
- A 12V supply and suitable on-deck mounting space are required.
Best for: Owners who want a horizontal windlass package with foot and rocker controls, electrical protection, rode, and mounting hardware included.
Not ideal for: Buyers requiring a vertical installation or relying on 1/2-inch chain compatibility without confirming gypsy fit.
- Orientation and installation:Horizontal, on-deck
- Power:12V
- Motor power:600W
- Maximum pulling capacity:1,200 lb / 540 kg
- Maximum working load:400 lb / 180 kg
- Included rope:1/2 in three-strand nylon, 150 ft
- Included chain:1/4 in galvanized HT G4, 15 ft
- Circuit breaker:60A
- Recommended boat length:20–45 ft
Our verdict“Select this kit for its broad set of included controls and components if a horizontal on-deck layout fits your boat.”
Excalibur 600W 12V Vertical Windlass Anchor System for Boats up to 40 ft
For a roundup specifically about vertical windlasses, the Excalibur 600W is the clearest fit: its below-deck motor and gearbox keep the deck profile clean, while its gypsy handles both 1/4-inch HT G4 chain and 1/2-inch three-strand rope. Compared with the VEVOR fishing windlass, Excalibur offers a higher stated maximum pull of 990 lb and a broader conventional anchor-windlass setup, though VEVOR lists a faster 65 ft/min retrieval speed and free-fall release. The Excalibur’s 85 ft/min drop speed is useful for deployment, but the supplied details do not list free-fall operation. It is rated for boats up to 40 ft and draws 33A, so electrical capacity and vessel fit need attention. Its 330 lb working load remains below the Five Oceans horizontal kits’ 400 lb rating.
Pros:- Vertical layout with below-deck motor and gearbox keeps the deck profile clean.
- Handles compatible 1/4-inch HT G4 chain and 1/2-inch three-strand rope.
- 990 lb maximum pull exceeds the VEVOR vertical fishing windlass’s 700 lb rating.
- Includes solenoid, 60A circuit breaker, switches, and mounting hardware.
Cons:- 330 lb working load is lower than the Five Oceans Atlantic 600 Series kits’ 400 lb rating.
- Requires 12V DC power and draws 33A.
- Specified for boats up to 40 ft, with no stated free-fall feature.
Best for: Owners of boats up to 40 ft seeking a vertical windlass with a below-deck motor and compatible rope-and-chain handling.
Not ideal for: Boaters who need a working-load rating above 330 lb, free-fall operation, or who cannot provide a 12V supply for a 33A draw.
- Orientation:Vertical
- Motor power:600W
- Voltage:12V DC
- Current draw:33A
- Maximum pull:990 lb / 450 kg
- Working load:330 lb / 150 kg
- Drop speed:85 ft/min / 26 m/min
- Rode compatibility:1/4 in HT G4 chain; 1/2 in three-strand rope
- Boat size:Up to 40 ft
Our verdict“Choose the Excalibur for a clean-profile vertical installation with rope-and-chain capability, provided its 330 lb working load fits your anchoring demands.”
Five Oceans Atlantic 600 Series 12V Horizontal Electric Windlass Anchor Kit
The Atlantic 600 Series earns this role by arriving as a more complete rode-and-control package than the vertical options here: it includes 150 feet of nylon rope, 15 feet of chain, switches, breaker, and mounting hardware. Its 600W motor offers up to 1,200 pounds of pulling power, while the single gypsy handles rope and chain, reducing the need to piece together compatible components. Compared with the Excalibur 900W Vertical Windlass, it gives up motor power and a below-deck layout, but its on-deck installation may suit boats where space beneath the foredeck is limited. The tradeoff is a larger exposed deck unit, and the stated 20–45-foot boat range depends on the vessel’s design and displacement. Buyers focused specifically on a vertical windlass should look elsewhere.
Pros:- Includes 150 feet of nylon rope and 15 feet of galvanized chain
- Single gypsy handles rope and chain
- 600W motor provides up to 1,200 pounds of pulling power
- Kit includes switches, breaker, solenoid, and mounting hardware
Cons:- Horizontal, on-deck layout does not meet a preference for a vertical windlass
- Boat-length guidance varies with hull design and displacement
- One-year warranty is shorter than the Lewmar V700’s stated five-year warranty
Best for: Owners of 20–45-foot boats who want a horizontal windlass kit with rode, controls, and mounting parts included.
Not ideal for: Buyers who need a vertical windlass or want to keep the motor and gearing below deck; this is designed for on-deck installation.
- Type:Horizontal electric windlass
- Voltage and motor power:12V DC, 600W
- Maximum pulling power:1,200 lb (540 kg)
- Maximum working load:400 lb (180 kg)
- Chain:1/4 in (7 mm) HT G4 galvanized chain, 15 ft
- Rope:1/2 in (12 mm), three-strand nylon, 150 ft
- Installation and boat length:On-deck; 20–45 ft depending on vessel design and displacement
- Warranty:1 year
Our verdict“Choose this kit if you want a supplied rode and controls in a capable horizontal package, but skip it if a vertical layout is a firm requirement.”
Excalibur 900W 12V Vertical Windlass Anchor System for Boats up to 40 ft
Among the vertical models in this group, the Excalibur 900W stands out for buyers prioritizing retrieval speed and stronger stated capacity. Its chain speed reaches 131 feet per minute, and the 1,452-pound maximum pull exceeds the figures listed for the Lewmar V700 12V model and the VEVOR fishing windlass. That extra capability comes with a real electrical and installation demand: the unit draws 55A, uses a 90A breaker, and needs room beneath the deck for its motor and gearing. Its 316 stainless steel housing and compatibility with 1/4-inch HT G4 chain and 1/2-inch three-strand rope make it a flexible choice for mixed rode. Compared with the horizontal Five Oceans Atlantic kit, it keeps the machinery below deck but does not include rope or chain, so buyers must source the rode separately.
Pros:- Fast stated chain retrieval speed of 131 ft/min
- Maximum pull of 1,452 lb and working load of 484 lb
- Accepts 1/4-inch HT G4 chain and 1/2-inch three-strand rope
- Installation kit includes switches, solenoid, breaker, and mounting hardware
Cons:- 55A current draw and 90A breaker require a suitably sized electrical system
- Vertical motor and gear assembly need below-deck clearance
- Rope and chain are not listed among the included components
Best for: Owners of boats up to 40 feet who regularly retrieve chain quickly and have adequate below-deck clearance and 12V electrical capacity.
Not ideal for: Owners with limited space beneath the foredeck, modest electrical systems, or a preference for a kit that supplies the anchor rode.
- Type:Vertical electric windlass
- Voltage and motor power:12V DC, 900W
- Current draw:55A
- Maximum pull and working load:1,452 lb (660 kg); 484 lb (220 kg)
- Chain retrieval speed:131 ft/min (40 m/min)
- Rode compatibility:1/4 in HT G4 chain; 1/2 in (12 mm) three-strand rope
- Housing and weight:316 stainless steel; 20 lb (9 kg)
- Boat length:Up to 40 ft
- Circuit breaker:90A
Our verdict“Pick the Excalibur for fast retrieval and higher stated pull capacity if your boat can accommodate its electrical draw and below-deck machinery.”
VEVOR 12V DC Fishing Windlass for Boats 23-29.5 ft, Max Pull 573 lbs, Stainless Steel
The VEVOR fishing windlass is the narrowest-fit choice here: its specified 23–29.5-foot range gives smaller-boat owners a clearer target than the broader recommendations attached to the Five Oceans Atlantic kit. Its 573-pound maximum pull and free-fall deployment suit fishing setups where quick anchor release is useful, while 316 stainless steel is a sensible material choice for marine exposure. It accepts 1/4-inch chain and thicker 9/16–5/8-inch nylon rope, unlike the Excalibur 900W, which is specified for 1/2-inch rope. The limits are just as relevant: no motor wattage, working load, or control package is provided in the supplied data, and no remote control is included. This is a more specialized option than the Lewmar V700, with a tighter boat-size window and less documented operating detail.
Pros:- 316 stainless steel construction
- Free-fall design supports quick anchor deployment
- Accepts 1/4-inch chain and 9/16–5/8-inch nylon rope
- Specified for a focused 23–29.5-foot boat range
Cons:- Maximum pull of 573 lb is lower than the Excalibur 900W’s stated capacity
- No remote control is included
- Motor power and working load are not specified in the provided data
Best for: Fishing-boat owners in the 23–29.5-foot range who want free-fall deployment and use 1/4-inch chain with thicker nylon rope.
Not ideal for: Owners outside the stated boat-length range or buyers who need included remote controls, a specified working load, or detailed motor-performance figures.
- Type:12V DC fishing windlass
- Maximum pull:573 lb
- Suitable boat length:23–29.5 ft
- Material:316 stainless steel
- Chain compatibility:1/4 in
- Rope compatibility:9/16–5/8 in nylon rope
- Deployment:Free-fall design
- Remote control:Not included
Our verdict“Choose this compact fishing-oriented option if your boat fits its stated range and free-fall operation matters more than higher documented pull capacity.”
Lewmar V700 Vertical Windlass with Solenoid and Rocker Switch
The Lewmar V700 is the most chain-specificity-friendly choice among these vertical windlasses. Its gypsy is listed for several calibrated sizes—6 mm DIN766, 1/4-inch G4 or BBB, and 7 mm DIN766—so owners can match the unit to an existing chain standard rather than assuming all similarly sized chain will fit. The flush-mount 316 stainless steel deck unit leaves the motor below deck, and anchor lock, motor protection, and manual recovery add useful safeguards and a backup method. Compared with the Excalibur 900W, the V700’s supplied data gives less emphasis to speed and maximum pull, so it is a less compelling pick for buyers chasing rapid retrieval or higher capacity. Its stated maximum boat length is 35 feet, and chain compatibility remains limited to the named types. The five-year warranty is the longest specified among these five products.
Pros:- Gypsy supports several specified chain sizes and standards
- Flush-mount deck unit places the motor below deck
- Includes anchor lock, motor protection, and manual recovery
- Five-year warranty
Cons:- Chain fit is limited to the listed calibrated sizes and types
- Specified for boats up to 35 ft
- Maximum pull and retrieval speed are not provided in the supplied product data
Best for: Owners of boats up to 35 feet who need a vertical windlass matched to one of several listed calibrated chain standards.
Not ideal for: Owners using unlisted chain or boats above 35 feet, and buyers who want a published retrieval speed or maximum pull figure before choosing.
- Model:Lewmar V700
- Deck unit material:316 stainless steel
- Chain compatibility:6 mm DIN766, 1/4 in G4 or BBB, 7 mm DIN766
- Maximum boat length:10.5 m (35 ft)
- Installation layout:Flush-mount deck unit; motor below deck
- Safety and recovery features:Fall-safe anchor lock, motor protection, manual recovery
- Included electrical components:Contactor and circuit breaker
- Warranty:5 years
Our verdict“Choose the V700 when matching an existing calibrated chain and having manual recovery matter more than published speed or pull figures.”
Lewmar V700 12V Vertical Windlass for 1/4-Inch G4 Chain
This Lewmar V700 12V is the straightforward choice for buyers whose rode already uses 1/4-inch G4 chain. Its specified 700-pound maximum pull, 316 stainless steel construction, and supplied rocker switch, breaker, two-direction solenoid, and handle give the core windlass setup a practical level of detail. FastFit clamping is intended to help align the deck unit and motor during installation, a useful aid when fitting a vertical model with below-deck components. Compared with the other Lewmar V700 in this group, this listing clearly states voltage and maximum pull but specifies only 1/4-inch G4 chain; the other listing names more chain standards and adds manual recovery and anchor-lock details. It is less flexible if your chain differs, and its 12V requirement means it is not suitable for a different electrical system.
Pros:- 700 lb maximum pull is specified
- FastFit clamping supports alignment during installation
- 316 stainless steel construction
- Includes rocker switch, breaker, two-direction solenoid, and handle
Cons:- Specified for 1/4-inch G4 chain only
- Requires a 12V power supply
- Three-year warranty is shorter than the five-year warranty listed for the other Lewmar V700
Best for: Owners of boats already rigged with 1/4-inch G4 chain who want a 12V vertical windlass with key electrical components included.
Not ideal for: Owners using another chain standard or boats without a compatible 12V supply; the specified chain fit is narrower than the other Lewmar V700 listing.
- Model:Lewmar V700
- Voltage:12V
- Maximum pull:700 lb
- Compatible chain:1/4 in G4
- Material:316 stainless steel
- Weight:19.4 lb
- Installation feature:FastFit clamping system
- Included components:Windlass, rocker switch, breaker, two-direction solenoid, handle
- Warranty:3 years
Our verdict“Pick this V700 if you have 1/4-inch G4 chain and want a clearly specified 12V package, but choose the other V700 listing for broader stated chain compatibility.”
Lewmar Pro Sport 550 12V Windlass for 1/4″ G4 Chain, Manual Freefall, Port Side Mounted, for Boats 20′-30′
The Lewmar Pro Sport 550 is the most size-specific choice here: its 550-pound maximum pull and 1/4-inch G4 chain fit the stated 20–30-foot boat range. Its compact profile and port-side mounting make it a more targeted fit than the larger horizontal Five Oceans 600W kits, which are rated for a wider boat-length range but need room on deck. The listed kit includes the components for an anchoring setup, which can simplify sourcing, though it still requires electrical installation. The tradeoff is limited headroom: this is not the pick for a heavier boat or demanding anchoring loads, and the supplied data does not give a line speed or working-load figure. Choose it for a smaller vessel whose chain and installation layout match its specifications.
Pros:- 550-pound maximum pull is specified for a clear size-and-capacity match.
- Compact construction suits installations where deck space is limited.
- Port-side mounting is specified, helping buyers check fit against their anchor setup.
- Includes components for a complete anchoring system.
Cons:- Its stated boat range stops at 30 feet, limiting use on larger vessels.
- 550-pound maximum pull may not suit heavier anchoring loads.
- Requires a 12V electrical hookup and installation work.
Best for: Owners of 20–30-foot boats using 1/4-inch G4 chain who want a compact, port-side windlass and a kit with installation components.
Not ideal for: Owners of boats over 30 feet or heavier vessels that need more pulling capacity, as well as buyers seeking a horizontal on-deck model.
- Voltage:12V
- Maximum pull:550 lbs.
- Chain compatibility:1/4-inch G4 chain
- Mounting side:Port side
- Recommended boat length:20–30 ft
- Freefall:Manual
Our verdict“Choose the Pro Sport 550 for a 20–30-foot boat that needs a compact port-side chain windlass, not extra capacity for a larger vessel.”
Five Oceans 12V Electric Boat Anchor Windlass Kit, 600W
This Five Oceans 600W kit is the practical choice for buyers who want the rode and electrical parts supplied together: it includes 150 feet of three-strand nylon rope, 15 feet of galvanized G4 chain, controls, a solenoid, circuit breaker, and mounting hardware. Its single gypsy handles rope and chain, so the setup can retrieve a mixed rode rather than chain alone. Compared with the Lewmar Pro Sport 550, it offers a higher stated maximum pull and a broader recommended boat-length range, but it is a horizontal, on-deck design—not a vertical windlass—and needs suitable deck space. The 1,200-pound maximum pull should not be confused with its 400-pound maximum working load. It suits buyers prioritizing an included system over a compact vertical installation.
Pros:- Includes 150 feet of rope, 15 feet of chain, controls, electrical components, and mounting hardware.
- Single gypsy is compatible with the supplied rope-and-chain combination.
- IP66-rated motor and polished, anodized 316 stainless steel housing are specified.
- Maximum pulling power is listed as 1,200 lbs.
Cons:- Horizontal on-deck installation requires sufficient mounting space.
- Maximum working load is 400 lbs., well below the stated maximum pulling power.
- The 20–45-foot recommendation depends on vessel design and displacement.
Best for: Owners of 20–45-foot boats, subject to vessel design and displacement, who need a complete rope-and-chain kit and have space for horizontal on-deck mounting.
Not ideal for: Buyers specifically seeking a vertical windlass or those with limited deck space; also skip it if the vessel’s load needs exceed the stated 400-pound working load.
- Windlass type:Horizontal, on-deck
- Voltage and motor power:12V, 600W
- Maximum pulling power:1,200 lbs. / 540 kg
- Maximum working load:400 lbs. / 180 kg
- Rope:1/2-inch (12 mm) three-strand nylon, 150 ft
- Chain:1/4-inch (7 mm) galvanized HT G4, 15 ft
- Housing:Polished, anodized 316 stainless steel
- Motor protection:IP66
- Warranty:1 year
Our verdict“Pick this kit if a supplied mixed rode and installation hardware matter more than a vertical layout or a higher working-load rating.”
Five Oceans Atlantic 600 Series 12V Horizontal Electric Boat Windlass Kit
The Atlantic 600 Series is a horizontal kit for buyers who want both the rode and more than one control option in the package. It handles the listed 1/4-inch G4 chain and 1/2-inch three-strand nylon rope on a single gypsy, with a spring-loaded tension arm for managing the line-and-chain feed. Compared with the other Five Oceans 600W kit in this group, its supplied up/down foot switch and rocker switch are explicitly identified, along with a 60A circuit breaker. The motor and 316 stainless housing share the marine-protection emphasis of that alternative, while the core capacity figures remain 1,200 pounds maximum pull and 400 pounds working load. Like its sibling, it needs on-deck space and is not a vertical windlass; choose it when the included controls suit your installation.
Pros:- Includes both up/down foot and rocker switches.
- Single gypsy handles the specified rope-and-chain rode.
- Includes 150 feet of nylon rope, 15 feet of G4 chain, and mounting hardware.
- IP66 motor and polished, anodized 316 stainless steel housing are specified.
Cons:- Horizontal on-deck installation needs appropriate mounting space.
- 400-pound maximum working load is substantially below its 1,200-pound maximum pull.
- Recommended boat length varies with vessel design and displacement.
Best for: Boat owners who want a horizontal rope-and-chain windlass kit with both foot-switch and rocker-switch controls included.
Not ideal for: Buyers who need a vertical windlass, cannot spare on-deck mounting space, or need a working-load rating above 400 lbs.
- Installation:Horizontal, on-deck
- Voltage and motor power:12V, 600W
- Maximum pulling power:1,200 lbs. / 540 kg
- Maximum working load:400 lbs. / 180 kg
- Chain:1/4-inch (7 mm) galvanized HT G4, 15 ft
- Rope:1/2-inch (12 mm) three-strand nylon, 150 ft
- Included controls:Up/down foot switch and rocker switch
- Circuit breaker:60A
- Warranty:1 year
Our verdict“Choose the Atlantic 600 Series when you want its clearly specified dual controls and included rode in a horizontal installation.”
Lewmar Pro-Fish 700 Fishing Windlass with Auto Free-Fall
The Lewmar Pro-Fish 700 stands apart from the supplied-rode Five Oceans kits with automatic free-fall and a stated line speed of up to 100 feet per minute, features aimed at quick anchor deployment rather than an all-in-one rope-and-chain package. Its 316 stainless steel construction and included electrical components support a more complete installation than a bare windlass, while its stated 28–38-foot boat range suits vessels larger than the Lewmar Pro Sport 550 targets. There is an important specification conflict: the title says 700 pounds of pull, while the description says 1,000 pounds. I would not size an installation around the higher figure without confirming it with the manufacturer. It is also a horizontal, above-deck unit, so it does not fit a buyer committed to a vertical layout.
Pros:- Automatic free-fall supports quick anchor deployment.
- Line speed is listed at up to 100 feet per minute.
- 316 stainless steel construction is specified.
- Includes a circuit breaker, guarded rocker switch, solenoid, hardware, template, and manual.
Cons:- Maximum pull is inconsistent in the supplied data: 700 lbs. in the title versus 1,000 lbs. in the description.
- Designed for 1/4-inch G4 chain and a specified 28–38-foot boat range.
- Above-deck horizontal installation does not meet a vertical-windlass requirement.
Best for: Owners of 28–38-foot boats using 1/4-inch G4 chain who prioritize rapid anchor deployment and automatic free-fall.
Not ideal for: Buyers requiring a vertical windlass, supplied rope and chain, or a confidently established maximum-pull rating before purchase.
- Installation:Above-deck, horizontal
- Chain compatibility:1/4-inch G4
- Recommended boat length:28–38 ft
- Maximum pull:700 lbs. in title; 1,000 lbs. in description
- Maximum line speed:100 ft/min
- Material:316 stainless steel
- Dimensions:7 x 5-3/4 x 9-5/8 in
- Weight:28.4 lbs.
- Warranty:3 years
Our verdict“Choose the Pro-Fish 700 for fast deployment on a compatible boat only after verifying its conflicting pull specification.”
Excalibur 600W Vertical Windlass Anchor System with Capstan, 12V DC
Unlike the horizontal Five Oceans kits, the Excalibur 600W matches a buyer specifically seeking a vertical windlass and adds a capstan for handling lines. Its 12V motor is rated at 992 pounds maximum pull, but the listed working load is 330 pounds; that lower figure is the more useful limit when judging routine load capacity. The kit includes controls, a solenoid, circuit breaker, mounting hardware, and an installation template, while its 1/4-inch HT G4 chain and 1/2-inch three-strand rope compatibility covers a common mixed-rode setup. The 316 stainless steel housing and IP66-rated motor are suited to marine exposure. Compared with the Lewmar Pro Sport 550, it offers a capstan and a higher stated pull, but it still requires electrical supply and careful capacity matching.
Pros:- Vertical format directly suits buyers who need a vertical windlass.
- Capstan provides an additional option for handling lines.
- Compatible with 1/4-inch HT G4 chain and 1/2-inch three-strand rope.
- Includes switches, solenoid, circuit breaker, and mounting materials.
Cons:- 330-pound working load is well below the 992-pound maximum pull.
- Requires a 12V DC power supply and electrical installation.
- The supplied specifications do not state a recommended boat-length range.
Best for: Owners seeking a 12V vertical windlass for 1/4-inch HT G4 chain who also want a capstan for line handling.
Not ideal for: Buyers needing a working-load rating above 330 lbs., or those without a suitable 12V supply and space for vertical installation.
- Windlass format:Vertical
- Motor and voltage:600W, 12V DC
- Current draw:33A
- Maximum pull:992 lbs. / 450 kg
- Working load:330 lbs. / 150 kg
- Drop speed:85 ft/min (26 m/min)
- Chain and rope:1/4-inch HT G4 chain; 1/2-inch three-strand rope
- Housing and motor protection:AISI 316 stainless steel; IP66-rated motor
- Circuit breaker:60A
Our verdict“Choose the Excalibur if a vertical layout and capstan matter, while sizing your setup around its 330-pound working load rather than its peak pull.”
How We Picked
I ranked these options by how directly they answer a buyer seeking a vertical anchor windlass, then weighed stated power, chain compatibility, boat-size guidance, included controls, and useful features such as free-fall or a capstan. I also separated conventional anchor windlasses from fishing-focused windlasses, since their intended jobs and rode handling may differ. Where a title identifies a horizontal model, I treat it as an alternative layout—not as a vertical pick.
The ranking favors products with a clearly stated vertical configuration and buyer-relevant specifications. That puts the Lewmar V700 and Excalibur vertical systems ahead of the horizontal Five Oceans options for this specific search. The repeated Five Oceans titles are not counted as distinct advantages: buyers should confirm exact model numbers and package contents before choosing among them. A product’s position reflects fit and information clarity, not a claim that every boat needs the most powerful unit.
Factors to Consider When Choosing Vertical Anchor Windlass
Before choosing by brand or motor wattage, I would check the boat, rode, and installation as one system. These broader checks can prevent an otherwise capable windlass from becoming an expensive mismatch.
Match the windlass layout to the bow
A vertical windlass places much of its mechanism below deck, which can leave a cleaner-looking foredeck, but it needs enough unobstructed space beneath the mounting surface. Check for lockers, wiring, structural members, and access for future service before settling on this layout. A horizontal unit may suit a shallow or crowded installation better, even if vertical is your preferred style. Do not compare the Five Oceans horizontal models as direct vertical replacements without accounting for that difference. Also confirm the chain falls freely into the locker rather than piling under the gypsy. A careful layout check is more useful than choosing a motor first.
Verify the exact rode and gypsy match
Chain diameter alone does not tell the whole story: chain grade and link pattern can affect whether it feeds correctly through a gypsy. Rope-and-chain combinations also need a gypsy designed for the specific rode, not simply a windlass advertised for a similar boat length. Check the manufacturer’s compatibility details against the chain and rope you actually carry. A mismatch can cause slipping, poor retrieval, or unnecessary wear regardless of motor output. If your rode is not listed clearly, ask the seller or manufacturer for confirmation before installation. This matters especially when comparing V700 listings that specify particular chain sizes.
Size for real anchoring loads, not boat length alone
Boat-length guidance is a starting point, not a full sizing method. Anchor weight, chain length, windage, bottom conditions, and how often you anchor all change the load placed on a windlass. Higher wattage may offer more retrieval capacity, but it does not replace correct anchoring practice or a suitable chain stopper. Avoid buying the most powerful model automatically; extra capacity can bring added installation demands and may not solve a poor rode setup. Conversely, a lightly specified unit can struggle if the boat regularly anchors in demanding conditions. Use the maker’s load guidance and your actual ground tackle together.
Plan the electrical installation before purchase
A 12V label does not mean every boat can run a windlass from existing wiring. Cable length, conductor size, battery condition, protection, and solenoid placement all affect performance and safe operation. Long runs can cause voltage drop, so estimate the route from battery to windlass before selecting cable and circuit protection. Check whether controls such as a rocker switch or solenoid are included, since packages differ and missing parts can complicate the project. Keep the windlass circuit and installation aligned with the manufacturer’s instructions and applicable marine standards. Buyers who are unsure about high-current wiring should budget for qualified installation.
Choose controls and retrieval features around your routine
Free-fall can speed anchor deployment, but it also calls for a setup and operating routine that keeps the rode controlled. A manual free-fall option, automatic free-fall, and standard powered retrieval are not interchangeable conveniences; each changes how the anchor is released. A capstan can help with line handling, but it adds another function to understand and maintain. Consider whether you anchor alone, need controls at the helm, or can operate safely from the bow. Extra features are useful only when they match how you handle the anchor. Keep a manual backup plan in case electrical power or controls fail.
Compare complete packages and service access
Windlass listings may differ in whether they include a switch, solenoid, wiring, or other installation parts. A lower-feature package can still be the right fit, but only if you account for the components needed to finish the system. Repeated or closely worded listings—especially among the Five Oceans Atlantic 600 entries—deserve a model-number check before ordering. Ask how the unit can be inspected, lubricated, and repaired once installed; below-deck access can be tight on some boats. Favor a configuration you can service without dismantling nearby equipment. Long-term access can matter more than a small difference in advertised motor power.
Frequently Asked Questions
Can I use a horizontal windlass if I searched for a vertical one?
Yes, if the horizontal layout fits your bow better and you are not committed to the below-deck motor arrangement. Horizontal and vertical models differ in deck footprint, under-deck clearance, rode path, and service access, so compare the installation drawing rather than the label alone. The Five Oceans Atlantic 600 entries in this roundup are horizontal options, not substitutes with a vertical configuration. Measure the mounting area and locker before deciding. If the vertical layout is a firm requirement, focus on the V700 and Excalibur vertical listings.
How do I know whether a windlass gypsy will work with my existing chain?
Match the chain’s diameter, grade, and link pattern to the windlass maker’s compatibility information. A nominally similar chain size may not feed correctly if the link dimensions differ. Check the specified rode for the exact product version, not only the product family name. If you use a rope-and-chain rode, confirm that the gypsy supports that combination as well. When details are missing from a listing, get written confirmation before buying rather than planning to adapt the chain afterward.
Is a higher-wattage windlass always the safer choice?
No. More motor power can help with heavier retrieval demands, but safe operation also depends on correct sizing, compatible rode, sound electrical installation, and proper use of a chain stopper or cleat. A windlass should retrieve the anchor; it should not carry the boat’s load while anchored. Compare the maker’s capacity guidance with your ground tackle and expected conditions. The Excalibur 900W may suit buyers seeking more stated power than the 600W options, but that alone does not make it the right fit for every boat.
Should I choose automatic free-fall for easier anchoring?
Automatic free-fall can make deployment quicker, especially when you anchor often, but it requires controlled handling and familiarity with how the rode releases. It may be less appealing if you prefer a slower, more deliberate deployment or have a bow arrangement where uncontrolled slack is a concern. Check how the feature is engaged and what backup procedure the manufacturer provides. Also make sure the anchor and rode can run clear of the hull and other gear. Choose it for a routine benefit you will use, not simply because it appears on the feature list.
Why do several listings have nearly identical Five Oceans names?
Similar titles can reflect duplicated product entries, package variations, or listing differences that are not obvious from the name. Do not assume each is a distinct windlass or that the included components match. Compare exact model numbers, mounting orientation, motor specifications, gypsy compatibility, and package contents before ordering. In this roundup, the Atlantic 600 entries are horizontal, so a repeated listing does not make them vertical options. If the seller cannot clarify the exact configuration, choose a listing with verifiable specifications.
Conclusion
For most buyers committed to a vertical layout, I would start with the Lewmar V700 as the best overall pick, then verify the exact chain specification and included controls. The Excalibur 600W is the value-minded vertical option when its stated configuration fits your boat, while the Excalibur 900W is the premium direction for buyers who need a higher-powered system. Beginners should favor the clearest package and support details over extra features, making a well-specified V700 listing a sensible place to start. Choose the Excalibur capstan version for added line-handling utility, or the Lewmar Pro-Fish 700 or VEVOR models when fishing-focused retrieval is your actual need. The Five Oceans Atlantic 600 models remain alternatives for buyers willing to install a horizontal windlass; they do not meet a strict vertical-only requirement.
